Hello ROS developers! In this post, you’ll learn how to create a ROS2 workspace in four easy steps 🙂 . Let’s go!
COMMANDS TO USE
* mkdir -p my_ros2_ws/src
* colcon build
* source ~/my_ros2_ws/install/local_setup.bash
The Four Easy Steps to Creating a ROS2 Workspace
Let’s jump straight in. Here I’m giving the four steps “upfront”; practical demonstrations follow.
Step
Description
1
Install ROS2 I will use ROSDS for this example, which allows me to create a ROSject which already has ROS2 Crystal installed on it . Heck, no time to go through the installation now. Unless you have > 24 hours per day, you can try ROSDS too 🙂
2
Create workspace directory ~$ mkdir -p ros2_ws/src && cd ros2_ws
3
Build workspace with colcon ~/ros2_ws$ colcon build
Already got the idea? Great, rush off to your terminal and get the job done! The rest of us will proceed to the practicals.
Practicals: Executing the Four Easy Steps to Creating a ROS2 Workspace
Easier said than done, right? No, for this case, it’s easier done than said. Take a look:
Step 1
Either of the following will do:
Use the ROS Development Studio (ROSDS), an online platform for developing for ROS within a PC browser. Easy-peasy. I’m using this option of this post. To open a “terminal” on ROSDS, pick the Shell app from the Tools menu.
You have ROS2 installed on a local PC. Okay, skip to step 2.
Next step!
Step 2
Straight to the point:
root@086ad5448257:/# cd ~
root@086ad5448257:~# mkdir -p ros2_ws/src && cd ros2_ws
root@086ad5448257:~/ros2_ws#
Step 3
Now for the real deal…build the workspace:
root@086ad5448257:~/ros2_ws# colcon build
Summary: 0 packages finished [0.13s]
root@086ad5448257:~/ros2_ws# ll
total 24
drwxr-xr-x 6 root root 4096 Feb 20 20:19 ./
drwx------ 6 root root 4096 Feb 20 20:17 ../
drwxr-xr-x 2 root root 4096 Feb 20 20:19 build/
drwxr-xr-x 2 root root 4096 Feb 20 20:19 install/
drwxr-xr-x 3 root root 4096 Feb 20 20:19 log/
drwxr-xr-x 2 root root 4096 Feb 20 20:17 src/
root@086ad5448257:~/ros2_ws#
Step 4
Source the workspace, and you’re done:
root@086ad5448257:~/ros2_ws# source install/local_setup.bash && so
urce install/setup.bash
root@086ad5448257:~/ros2_ws#
Feedback
Did you like this post? Please leave a comment in the comments section below, so we can interact and learn from each other.
If you want to learn about other ROS topics, please let us know on the comments area and we will look into doing a post and/or video about it.
ROS2 Course for Beginners: Introduce you to the basic concepts that you need to know in order to start working with ROS2.
ROS Development Studio: Develop your first ROS2 project online (Ready online including Gazebo simulations + ros1_bridge)
The following steps take through the development as shown in the video:
Open ROS Development Studio and create a new project (use a suitable name for the project).
Activate the docker image for ROS2 by executing the following command in a SHELL $ docker run -it osrf/ros2:ardent-basic
The first command to know is ros2 topic list. This command is same as the rostopic list command in ros1.
The command for publishing a topic is ros2 topic pub. This command takes the topic name and message just like the rostopic pub command in ros1.
In ros2, we can use the command ros2 msg list to see all the supported message types
Now let’s see the usage with a String type message. We can see the structure of the String message with the following command $ ros2 msg show std_msgs/String
The output of this command will give us the information about the content of the message type String. To publish the message we will use the following command
Welcome to the ROS2 tutorial series. In this first video we are going to show How to launch a node in ROS2.
COMMANDS TO USE:
ros2 run
ros2 pkg list
ros2 pkg executables
source /opt/ros/crystal/setup.bash
Step1. Let’s do this in ROS Development Studio(RDS)
At first, we have to find a Linux computer, install ROS, build all the package we need and…crash…NOOOOO!!!
Of course, you can do all this painfully on your own computer, but…
We’ll use ROSDS through this ROS2 tutorial because we can easily build a project on it without setting up any environment locally. You can create an account here for free.
After logging in, click on the New ROSject button. Let’s call this project ros2_tutorial and open it by clicking on the Open ROSject button.
Step2. Launching a ROS2 node
If you know ROS1 you may remember that in order to run a node on that ROS version we use therosrun <package_name> <executable_name> command. With ROS2 it’s you almost don’t see any difference, given that we use ros2 run<package_name> <executable_name>.
Before launching a node we first need to know the list of ROS2 packages installed. We can do that with the following command:
ros2 pkg list
With the command above we can see that among the packages we have one named demo_nodes_cpp, as can be seen with ros2 pkg list | grep demo. To see the list of ROS2 executable files on our system we can run the command below:
ros2 pkg executables
The output provided by the command below is a list of <package_name> <executable_name>.In case you want to reduce the output and list only the desired package, by using grep we can do that. Given that we are interested on thedemo_nodes_cpppackage, let’s filter it with ros2 pkg executables | grep demo_nodes_cpp.
We can see that we have among the executable files we have one called talker and another one called listener. For former writes data on a topic while the latter listens to that topic and print the received messages.
Let’s first launch the listener in background:
ros2 run demo_nodes_cpp listener &
Now let’s launch the talker and see the logs of both nodes:
ros2 run demo_nodes_cpp talker
After running the talker you should see something like the messages below:
So this is the post for today. It is really simple, but let’s go step by step learning a little bit of ROS2 every day. Let’s keep pushing and we will be ROS2 experts in no time.
To conclude, in case you also want to learn ROS1, we have complete courses in python and C++ on that subject. You can take those courses by clicking on the links below:
Did you like this post? Whatever the case, please leave a comment on the comments section of our youtube (https://www.youtube.com/watch?v=8NgpjHOVCV8) video associated to this post. You can also subscribe to our channel and press the bell for a new video every day.
Hello ROS developers! In this post lets’ see how to create and test a publisher in ROS2 using Python (rclpy).
I break it down into “5 easy steps”, let’s see one by one:
Create a Python-based package in ROS2.
Create the python code for your publisher.
Edit package.xml.
Replace CMakeLists.txt with setup.py.
Run and test your python code in ROS2.
Let’s go!
1. Create a Python-based package in ROS2
At this point, I’m taking for granted that you already have the following in place:
Your ROS2 is installed and running. (Don’t have this? No issues, you can spin a free ROS2 development environment at ROSDS. No installation required, just a few clicks and you will have a fully-functional ROS2 installation within your browser.)
You have created a ROS2 workspace. Need help on this? See this tutorial.
Once you have crossed the two bridges above, you just need to run this command from the src folder of your ROS2 workspace:
~/ros2_ws/src$ ros2 pkg create ro2_pub_py
Here the name of the package is ros2_pub_py, and our workspace directory is ros2_ws. Feel free to name yours differently.
The final structure of your project should look something like this (when you have completed all steps):
Easy Step 1 done!
2. Create the python code for your publisher
Yes, you guessed right, we must write the publisher in Python, since this post says “using Python”. ROS2 official repo provides 3 different ways with examples on how to write the Python code.
In this post, we will use the “local function” method because…I like it and get to decide here :)…kidding…I think it’s still somewhat ROS1-like while showcasing the differences in ROS2. Take home bonus: try ‘translating’ the code into the “old school” and “member function” variants.
Enough small talk, let’s do the work! Create Python file located at `~/ros2_ws/src/ro2_pub_py/sos_publisher.py`. Here’s the code:
# Copyright 2016 Open Source Robotics Foundation, Inc.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
# http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
import rclpy
from std_msgs.msg import String
def main(args=None):
rclpy.init(args=args)
node = rclpy.create_node('sos_publisher')
publisher = node.create_publisher(String, 'sos')
msg = String()
def timer_callback():
msg.data = 'ObiWan Kenobi, please help me. You\'re my only hope'
node.get_logger().info('Publishing sos message: "%s"' % msg.data)
publisher.publish(msg)
timer_period = 0.5 # seconds
timer = node.create_timer(timer_period, timer_callback)
rclpy.spin(node)
# Destroy the timer attached to the node explicitly
# (optional - otherwise it will be done automatically
# when the garbage collector destroys the node object)
node.destroy_timer(timer)
node.destroy_node()
rclpy.shutdown()
if __name__ == '__main__':
main()
A few notes about the code above:
The statement import rclpy imports the ROS2 Python module. This is equivalent to import rospy in ROS1.
The statement from std_msgs import String imports the type of message the publisher uses. Basically no change from ROS1.
The statements from rclpy.init(args=args) to publisher = node.create_publisher(String, 'sos') initialize the ROS2 Python module and create a node sos_publisher publishing to the topic sos. Did you notice the subtle differences in how this is achieved in ROS1?
The variable timer provides similar functionality as rospy.Rate() in ROS1, providing the frequency at which a particular code block is repeated.
Next!
3. Edit package.xml
Actually, this step is technically part of creating the Python package, because the changes we are doing here is just indicating that it’s a Python package. But I wanted to call this out separately because I think it’s an important step.
Now, the original package.xml should look something like this after creating the package:
Change to the following, following the example given in the official repo:
<?xml version="1.0"?>
<?xml-model href="http://download.ros.org/schema/package_format2.xsd" schematypens="http://www.w3.org/2001/XMLSchema"?>
<package format="2">
<name>ros2_pub_py</name>
<version>0.0.0</version>
<description>TODO: Package description</description>
<maintainer email="user@todo.todo">user</maintainer>
<license>Apache License 2.0</license>
<exec_depend>rclpy</exec_depend>
<exec_depend>std_msgs</exec_depend>
<!-- These test dependencies are optional
Their purpose is to make sure that the code passes the linters -->
<test_depend>ament_copyright</test_depend>
<test_depend>ament_flake8</test_depend>
<test_depend>ament_pep257</test_depend>
<test_depend>python3-pytest</test_depend>
<export>
<build_type>ament_python</build_type>
</export>
</package>
You can spot the differences, right? Great, next step!
4. Replace CMakeLists.txt with setup.py
Similar to step 3 above, this is also something that’s related to package creation that I decided to call out separately. These steps are necessary because as of now ROS2 package creator does not yet support Python-based packages out of the box (the package.xml and CMakeList.txt are created for a C-based package by default). Hopefully, a future release would make these steps unnecessary.
Not in some many words:
Delete CMakeList.txt; we don’t need it here.
Add a setup.py properly configured for the package and python program.
Now time to ros2 run your code, but not so fast! Before we become ros2-run-happy, we need to take care of some basic things so that we don’t have bad surprises.
In your ROS2 workspace directory, run:
~/ros2_ws$ colcon build
Yes, we need to rebuild the package, after all those changes.
~/ros2_ws$ ros2 run ros2_pub_py sos_publisher
[INFO] [sos_publisher]: Publishing sos message: "ObiWan Kenobi, please help me. You're my only hope"
[INFO] [sos_publisher]: Publishing sos message: "ObiWan Kenobi, please help me. You're my only hope"
[INFO] [sos_publisher]: Publishing sos message: "ObiWan Kenobi, please help me. You're my only hope"
[INFO] [sos_publisher]: Publishing sos message: "ObiWan Kenobi, please help me. You're my only hope"
...
From another terminal, run the following commands and check the output:
~$ ros2 node list
/sos_publisher
~$ ros2 topic list
/parameter_events
/sos
~$ ros2 topic echo /sos
data: ObiWan Kenobi, please help me. You're my only hope
data: ObiWan Kenobi, please help me. You're my only hope
data: ObiWan Kenobi, please help me. You're my only hope
And we’re all done!
Final take away
I hope you found this post useful. I would suggest that you try following the post and creating your package from scratch, but in case you want to have a sneak-peek at the code used for this post, you can find it here: https://rds.theconstructsim.com/r/bayodesegun/ros2_demo_4698/.
—
Feedback
—
Did you like this video? Do you have questions about what is explained? Whatever the case, please leave a comment on the comments section below, so we can interact and learn from each other.
If you want to learn about other ROS topics, please let us know on the comments area and we will do a video about it 🙂
This 14th of December of 2018, ROS2 Crystal Clemmyswas released officially. It’s a very important step due to the fact that it adds enough new functionality versus its prior older brother ROS2 Bouncy Bolson to be a real option to consider to make the jump from ROS to ROS2.
So here are some of my findings and facts about ROS2 versus ROS1. Just bear in mind that crystal is evolving really fast and it wouldn’t be a surprise that more improvements appear in the near future.
Use differences between ROS2 and ROS1
We will talk about ROS2 Crystal being the latest release. We will talk about the main basic differences in the way you use ROS2 versus ROS1:
Launch files using .xml format are gone. Forget what you knew about launching nodes and other launch files using the package structure. The system now relies upon python files launching binaries or python scripts. You will use the python module launch and package launch_ros. Here you have a basic example of how the binary tc_node from a package called the_construct_pkg would be launched now.
from launch import LaunchDescription import launch_ros.actions
Catkin_make is gone: Catkin has been replaced by colcon. This new building system is in essence a universal building system for the ROS ecosystem. This means that it can compile not only ROS2 packages, but packages from ROS1 or even packages without any manifest. This is really useful to compile non-ROS-Packages like Gazebo, which traditionally was something to compile separated from ROS. Its grammar is very similar to the good old catkin_make:
ROS Packages support exists but with some manual labor: ROS2 supports perfectly Cpp projects with the rclcpp. Python projects is another story. Although you can create rospackages that use python code with rclpy ros library in their scripts and rosrun those programs, the packages need to be configured manually for python use adding the ament_python export in the package xml. But that is defining the build type of the package and therefore, for the moment you won’t have easy mixing cpp and python code in the same package.
As for the main great features that ROS2 gives among others is the great capability of managing easily multiple robots and preliminary real-time programming support, features that are very welcomed by the community no doubt about that.
Can I use ROS2 completely forgetting ROS1? ROS1Bridge
The quick answer is: Yes but with drawbacks. So ROS2 Crystal has worked with the new GAzebo with ROS2 support, so you have access to creating your own simulations using only ROS2. You have access to the main ROS packages like tf, navigation, image_transport, rqt, and the big RVIZ. So it would seem that 90% of the current ROS users would be satisfied.
But the reality is that a huge amount of packages don’t come out of the bix working for ROS2 or are installed through debians. You will be obliged to compile them and probably make the modifications for ROS2 system. But there is an option which is using the ros1_bridge package.
This package allows you to run for example Gazebo simulations using ROS1, but communicate and control with ROS2 packages. It connects topics and services with the same message type and name. Crystal supports ros1bridge by default but only basic message types. If you want to use nonbasic message types, such as gazebo_ros_msgs you will have to compile ros1-bridge from source and in the same workspace have all the necessary messages you want to use with ROS2. Probably in the near future, it will support more message by default.
ROS2 Recommended?
Absolutely! It feels cleaner and faster for sure. And unless you need to use specific packages that don’t exist yet in ROS2 and are difficult to port, I would use it no doubt. Its obvious that ROS2 will become the main ROS on the long run and now its functional enough to do practically anything that you did with the good old ROS1. And you have the added bonus of all the improvements added to the mix. So my recommendation is to go there and have a try with ROS2.
If you are a previous ROS1 Developer:
You are bound to stumble upon some functionality that you were used to that now has no support or is buggy. But no doubt this is the future and is just like when rosbuild was removed back in the old days of ROS1. Just deal with the changes and you will see its worth the initial headaches. Here you have a migration ROS1 to ROS2 guide.
But I would highly recommend to for the next years until ROS2 gets total support, combine ROS1 and ROS2. Especially in simulations which are not yet ported to ROS2 because they tend to be the less updated and more critical to change. Just until more and more simulations get ROS2 versions.
If you are new in the ROS world:
You won’t notice most of the missing or buggy features that another person used to ROS1 would notice. You will undoubtedly have a headstart and ROS2 is not much more difficult to learn than ROS1, as far as the basics are concerned.
