Hello ROS Developers! In this post (and embedded video), we will see how to create a ROS Service Server (or simply ROS Service) in just five minutes! We’ll see in it action as well as learn some theory behind it.

Let’s go!

Step1: Create an account and/or Login to Robot Ignite Academy (RIA)

On RIA, you get access to the best online ROS courses and environment. No need to install and set up ROS locally; the only thing you need is a browser!

• Create an account and/or login here.
• Launch the ROS Basics in 5 Days Python course.
• You’ll now have access to the simulation screen with a Notebook, an Editor, four Shells, and a Simulation Window. We are only using the Editor and Shells for this demo.

Step 2: Create a ROS Service Server and call it!

ROS Services use a client/server approach. A server provides services, a client calls the server to use the services.

Here, we’ll create a simple service server based on Python and then call it from the command line, all in five easy steps! (In another post, we’ll see how to call the service server from Python code).

(1) On Shell #1, change to the source directory and create an executable python file (since this is a simple demo, we are not creating a ROS package):

user:~$ cd catkin_ws/src
user:~/catkin_ws/src$ touch sos_service.py
user:~/catkin_ws/src$ chmod +x sos_service.py
user:~/catkin_ws/src$

(2) Open sos_service.py in the Editor and copy-paste the following code into it.

#! /usr/bin/env python
import rospy                                      # the main module for ROS-python programs
from std_srvs.srv import Trigger, TriggerResponse # we are creating a 'Trigger service'...
                                                  # ...Other types are available, and you can create
                                                  # custom types
def trigger_response(request):
    '''
    Callback function used by the service server to process
    requests from clients. It returns a TriggerResponse
    '''
    return TriggerResponse(
        success=True,
        message="Hey, roger that; we'll be right there!"
    )

rospy.init_node('sos_service')                     # initialize a ROS node
my_service = rospy.Service(                        # create a service, specifying its name,
    '/fake_911', Trigger, trigger_response         # type, and callback
)
rospy.spin()                                       # Keep the program from exiting, until Ctrl + C is pressed

(3) Run the service server in Shell #1:

user:~/catkin_ws/src$ ./sos_service.py # press enter

(4) In Shell #2, see a list of available services, you should find /fake_911:

user:~$ rosservice list
...
/fake_911
...
user:~$

(5) Call your service in Shell #2:

user:~$ rosservice call /fake_911 "{}"
success: True
message: "Hey, roger that; we'll be right there!"

Let’s wrap up with a bit of “small talk” in the next section.

Step 3: Master the Concept: Creating a ROS Service Server

• A ROS Service Server accepts a request and returns a response. In this case, our server is the Python code.
• A ROS Service Client makes requests to a ROS Service Server. Our “client” in this case was the shell!

Please see the inline comments for an explanation of the code.

Done!

Extra: Video

Prefer to see the ‘sights and sounds’ version of this post? We made this video just for you!
